Product Description
Rawhide Pet Bone Pressing Machine with ISO9001 is type of Flour
Column and Three Board, the upmost output tonnage is 20t.
It can be adjusted amon the range of 5t-20t according to the
different products’procedures, the purpose is to arrive the best
required output. Cylinder Stroke is 200mm, (slide stroke is 200mm).
And the dimension of effective working surface is 500mm*400mm, the
close height is 200mm. Well, our DR-20T Pressing Machine has two
types, manual operation and automatic operation, meanwhile, it can
count and timing automatically, safe and protective.
In addition, our DR-20T Pressing Machine’s middle plate and lower
plate open two-article T-slot respectively, the pressure system is
rear-mounted and the below equips with horizontal floor mat.
Machine Picture
Technical Parameters
Project | DR-20T |
Liquid Pressure of Work (MPa) | 14-21 |
Theory Output (Ton)
| 5-20 |
Working surface size (mm)
| Left and Right 500 |
|
Working surface size (mm) | |
Front and Back 400 |
Height of Working Table Off the Ground(MM) | 780 |
Biggest Operational Height(mm) | 400 |
Close(mm) | 200 |
Cylinder Stroke(mm)
| 200 |
Motor Power | 5.5KW |
Structural Style | Flour Column Three Board |
| Above Oil Cylinder |
Power source
| 380VAC,50/60Hz |
Weight | 1108kg |
Dimension | 600*500*1780mm |
Sample Picture
Certificate
Customer Visit
Exhibition
Packing and shipping
Factory & Office
Commissioning Service
a. Consultation service before, during, and after sales;
b. Project planning and design service;
c.Debugging of equipment until everything is functional;
d. Management of equipments' long distance shipping from seller's
factory to the named place by buyer;
e.Training of equipment maintenance and operating personally;
f. New production techniques and formulas;
g. Provide 1 year complete warranty and life-time maintenance
service.
