Singe Screw extruder equipment / Nutrition Pet Treats Snacks Food
Extruder Machine
Introduction:
Singe Screw Pet Treats Machine takes starch as raw materials with
scientific configuration and was extruded from co-extrusion, it can
be made into many kind of shapes such as stick,bone ect. This kind
of food not only provide protein,fat,vitamin ,nutrition for dogs,
but also satisfy the dog nature hobby. It has following features:
strong teeth, clean mouth and teeth, good for diet. The products
can be in many shapes, like twist, double colors, core-filling and
so on.
Flow chart: Raw Material Mix – Screw Conveying – Extruding – Cooling – Cutting
– Drying -- Cooling
Products: make the pet food, like dog, cat, fish, bird food etc. with
different shapes and taste by changing the dies, formulations.
Technical Parameters
- Dog Chewing Food Machine can produce dog chew snacks and semi
moist pet food.
- It combines two processing lines into one: pet snacks and
semi-moist pet food.
- With different moulds, various shapes can be made, such as strip,
stick, screw shape, etc.
- All kinds of perfectly shaped non-crumbing chew snacks in a
variety of color combinations.
- Max. 3-color chew snacks can be produced.
- Various shapes can be made, such as strip, stick, bone, screw
shape, etc.
- Many kinds of recipes to make different tastes to meet different
market demands.
- Turnkey project provided, from raw materials to packing
procedures, fully continuous and automatic.
- Fully stainless steel 304.
Output | Installed Capacity | Actual Capacity | Voltage / Frequency | Dimension |
100-150kg/hr | 145kw | 102kw | 380V / 50Hz | 30 x 5 x 3m |
1. Motors are from WEG, Germay, which has 3-year world-wide
guarantee;
2. Electric parts are from ABB or Schneider, easy to find
replacments at local market;
3. PLC and touch screen are from Siemens, Germany to realize easier
operation and less labor quantity;
4. PLC and touch scrren controls whole processing line, not one or
two single equipment;
5. While faults occurred, relevant information will be displayed on
touch screen, easy to settle the problem;
6. Control cabinet has 24V safe voltage (not 220V), which could
protect the operator even electric leakage occurred;
7. Three kinds of protectors to keep machine and operator safe:
over-current protector, over-voltage protector and over-heat
protector;
8. All the cover body, mesh belt and parts touching with materials
or final products are made by stainless steel 304.
Machinery Show
